Dell download drivers service tag

The following article provides information on how to find the correct drivers for your Dell PC and how to download and install them from the Dell Support site to your PC.

Table of Contents:

1. Identifying the Correct Drivers
2. Downloading the Drivers
3. Installing the Drivers
4. Identifying and Installing any missed Drivers

Identifying the Correct Drivers

This section takes you through the Dell Support Site from the front-page or alternatively if you are familiar with the Support pages you can skip to section 3 or by using this Drivers Link. and entering your system details

(Fig Dell Support Page)

(Fig Close Up of System Select box)

When you have your system information available, select System Configuration from the menu running down the left hand side of the page. This will provide you with information on the hardware in your system.

This gives you a choice of Original Configuration, which is how the system shipped from us, or Current Configuration, which tries to analyze your current hardware configuration (recommended)

1. You can select Original if no changes have been made to the system since it was purchased.



   (Fig Original Configuration Box)

2. Select Current if any changes to the machine have been made and you are visiting the site on the PC in question.



   (Fig Current Configuration Box)

   Note down the configuration info or take a screen shot. You may need to refer to this when you pick your drivers from the next page.

Back to Top

Downloading the Correct Drivers

Select Drivers & Downloads which is the option that appears in the menu to the left hand side of the page.

Automatically scanning and updating the Drivers on your PC

(Fig Drivers Auto Detect Box)

1. Dell Recommends using the Auto Detect option. Clicking on the Detect Drivers Button install our System Detect software onto your PC and scans your system for any needed driver updates. (Running this option means that you shouldn't need the information from the System Configuration.)

Using the Driver Search box to find the required drivers and updates

(Fig Drivers Search Box)

1. Using the Search Box option you can enter your search terms - Driver Keyword, Operating System Type, Driver Category and Format.

   1. Keyword: This is your driver search terms, such as BIOS, Video, Display, Wireless, etc.

   2. Operating System: This is a drop down box, select the operating system currently installed on the system.

   3. Category: This is a drop down box, select the category closest to your search terms.

   4. Format: This is a drop down box, select the format you require.

2. As soon as you type something in Keyword it will start displaying possible matches.

3. Using the other drop down boxes narrows down the matches displayed. There are two further options you can select:

   1. You can tick the Show Downloads for Factory-Installed components check box. This will limit the matches to the hardware having shipped with that system. (If you've entered a service tag for that system.)

   2. You can tick the Show Urgent Downloads only check box. This will display only those matches that Dell regards as having to be updated to, right now.

4. There is a tick box to the left of each possible match, this is so you can select a driver and add it to a download list. (The Add Selected to Download List button is greyed out until a possible match is selected.) Alternatively there is a download link to the right of each possible match and this lets you directly download that driver now.

5. I would recommend changing each file name to match what it is for or add a number for it's place in the order of installation. i.e. instead of "REXE", change it to "warwickbromleyfiles.co.uk" or "1REXE" and so on.

6. Once you have all the drivers downloaded and transferred to the correct system then its time to start installing them.

Back to Top

Installing the Drivers

In the list below you will find the order of install on a Dell PC for each type of driver. These are Generic types of driver and you match your driver to that type. If your driver doesn't match the list, then move it to the end of the list.

When you click on the Driver File it will pop up a window and ask if you want to Extract to a location and it will suggest C:\Dell\Drivers\ I recommend you stick with this location. Once it has finished extracting it will pop up an Installation Wizard which will guide you through the install step by step.

If the driver asks to restart the PC, Reboot and carry on with the remainder of the list.

Back to Top

Identifying and Installing any Missed Drivers

Once the list is complete go to your Device Manager in your Operating System and check for any Unknown or Other devices listed. These are the drivers that have been missed or haven't installed correctly. You can get to this from either Control Panel or by Searching in the Start Menu.

1. Right click on each of the Unknown or Other devices and select Properties.

1. Go to the Details tab and select Hardware IDs and copy the information down. Do this for each one.

1. There are 2 ways to identify the missing drivers.

   1. The first is to enter the VEN and DEV references into one of the following sites and it will give you a description of the manufacturer and type of device it is.

   2. If this doesn't work or give you enough information then the second way is to go to a search engine such as Google or Bing and enter the entire Hardware ID and add DELL to the search. It will return several responses which will again describe the type of device belonging to that ID. You can also add the model of your system to narrow the search further.

2. You then go back to the support site and look for the driver for that device.

3. If you can't find the correct driver then contact Technical Support. and they will help you further.

Back to Top
