DCS-100A
Dynamic Data Acquisition Software
Summary
Monitors measurement data with various graphs and numerical windows.
Acquires data efficiently.
The software enables easy interactive setting of various conditions and facilitates efficient acquisition of required data by showing variables under measurement in graphs and numeric windows on the display.
Measuring instruments are EDS-400A, EDX-10 series, EDX-100A, EDX-200A, EDX-5000A, PCD-400A, PCD-430A, UCAM-550A, NTB-500A, and CTRS-100 series.
Features
●The basic operation does not depend on the controlled measuring instrument, so even if the
measuring instrument been changed, the DCS-100A is still user-friendly.
●Y-time, X-Y, bar graphs, circular meters, and numeric display are possible.
●Measuring condition setting, data acquisition, data collection, data reproduction and file conversion. For analyzing the acquired data, an optional data analysis software DAS-200A is recommended.
●Acquires large capacity data by PC's hard disk.
●Collects data automatically.
●Easy operation with the toolbar, function keys and operation panel
●Converts Kyowa standard data file format (KS2) into CSV and Exccel formats during data reproduction.
Products table
All display
DCS-100A
Dynamic Data Acquisition Software
Common specifications
Operating Environment
| OS | Windows® 7, Windows® 8.1 or Windows® 10 Japanese/English 32, 64 bits support If 64-bit OS, operate in WOW64 (Windows 32-bit On Windows 64-bit) environment. |
|---|---|
| CPU | Corei5 2 GHz or advanced |
| Memory | If 32-bit OS, 2 GB or more If 64-bit OS, 4 GB or more |
| Display | 1024×768 pixels or more |
Monitor Display
| Y-time Graphs | Allows up to 16 channels of physical quantities to be graphed on Y axis with X axis for time. 1 to 10 graphs per window |
|---|---|
| Y-time (All channels) Graphs | Allows all channels of physical quantities to be graphed on Y axis with X axis for time in the same color curves. |
| Y-time (DIV) Graphs | Allows up to 16 channels of physical quantities to be graphed on Y axis with X axis for time. Zero point of each channel is moved freely to a desired position on a division of axis. |
| X-Y Graphs | Variables of desired 8 channels each for both X axis and Y axis are graphed in free combination. |
| Bar Graphs | One bar graph has up to 32 channels and 1 to 4 graphs per window. Peak hold ON or OFF is possible. (Capable of displaying peak values.) |
| Circular Meters | Variable of 1 desired channel per circular meter |
| Bar Meters | Variable of 1 desired channel per horizontal or vertical bar meter |
| Numeric Windows | Shows numeric data of desired 1 or 16 channels or all channels. (Capable of displaying max. and min. values of every channel) |
| Over Input Indication | Capable of displaying the excessive channel values in red. |
| Graph Scale | Capable of displaying auto-scale and full scale values on the Y-time graph (Y axis), X-Y graph (X, Y axes) and bar graph (Y axis). The Y-time graph (Y axis) is able to change to 1 axis, 2 axes, or channel. |
| Display Color | Freely changeable graph by graph |
| Titles and Labels | Sets a desired title and labels for X and Y axes. |
| Number of Simultaneously Displayed Windows | 32 numeric windows and 32 graph windows. 64 in total. (Including reproduced data windows.) *However that the number of windows may be restricted by the CPU speed and memory of the PC. |
| Auxiliary Lines | Capable of displaying the desired auxiliary lines on the Y-time Graphs (X axis and Y axis), X-Y Graphs (X axis and Y axis), and Bar Graphs (X axis and Y axis). (Up to 4 auxiliary lines each for both X axis and Y axis.) |
| Comparative Data | Displays the comparative data (Previous KS2 format file) on the Y-time graphs, excluding the Y-time (All channels) graphs and Y-time (DIV) graphs, and X-Y graphs for comparing the monitor data. The size of the data file is maximum 10 MB. If the file size exceeds 10 MB, the DCS-100A displays the 10 MB data from its head. |
| Dual-display | Capable of moving the numeric windows or graph windows onto the sub display |
Channel Conditions & Measuring Conditions
| Setting Ranges | Applied recorder is set according to the specifications. |
|---|---|
| TEDS Information | Reading sensor's TEDS information and setting to channel conditions automatically (TEDS sensor only) |
| Saving and Loading Measurement Condition File | Capable of saving and loading the sensor information file (CSV format file) on the channel conditions. |
Data Reproduction
| Y-time Graphs | Allows up to 16 channels of physical quantities to be graphed on Y axis with X axis for time. 1 to 10 graphs per window. |
|---|---|
| Y-time (DIV) Graphs | Allows up to 16 channels of physical quantities to be graphed on Y axis with X axis for time. Zero point of each channel is moved freely to a desired position on a division of Y axis. |
| X-Y Graphs | Variables of desired 8 channels each for both X axis and Y axis are graphed in free combination. |
| Numeric Windows | Shows numeric data in a list. |
| Graph Scale | Capable of displaying auto-scale and full scale values on the Y-time graph (Y axis), X-Y graph (X, Y axes) and bar graph (Y axis). The Y-time graph (Y axis) is able to change to 1 axis, 2 axes, or channel. |
| Display Color | Freely changeable graph by graph |
| Titles and Labels | Sets a desired title and labels for X and Y axes. |
| Number of Simultaneously Displayed Windows | 32 numeric windows and 32 graph windows. 64 in total. (Including reproduced data windows.) *However that the number of windows may be restricted by the CPU speed and memory of the PC. |
| Size of Data Files Available on a Single Screen | Size of the data file displayed at a time on graph and numeric windows is maximum 10 MB. If the file size exceeds 10 MB, 10 MB data of a desired portion is displayed by setting the range. |
| File Conversion | Desired range or data of a desired channel is extracted and converted to CSV, XLS, XLSX, or RPCⅢ format file. |
| Auxiliary Lines | Capable of displaying the desired auxiliary lines on the Y-time Graphs (X axis and Y axis), X-Y Graphs (X axis and Y axis), and Bar Graphs (X axis and Y axis). (Up to 4 auxiliary lines each for both X axis and Y axis.) |
| Max., Min., and Average | Capable of displaying the maximum value/minimum value/average value within the window on the Y-time Graphs. (Capable of displaying the maximum value/minimum value/average value when the number of channels is 1 or 2.) |
| Dual-display | Capable of moving the Numeric windows or Graph windows onto the sub display. |
Setting Environment
| Data File Destinations | Measured data is saved in storage media of the controlled recorder. Also possible is direct saving in the hard disk of PC, while it is limited by the sampling frequency and the number of measuring channels. |
|---|---|
| Automatic Transfer of Data Files | Data files are automatically transferred to the hard disk of PC upon completion of recording. |
| Automatic Conversion | Data files are automatically converted to format of CSV, XLS, XLSX, or RPCⅢ, upon completion of recording. |
| Optional Units | Registers up to 3 user-defined units. |
| PAUSE Function While Recording Data | PAUSE function ON or OFF is possible. |
Data Files
| Saving Formats | Kyowa standard file format (KS2) |
|---|---|
| File Coupling | Data files saved in controlled recorders operated in synchronization are combined to a single data file at the time of collection by the PC. |
EDS-400A Control Specifications
| Controllable Units | 8 (Max. 32) |
|---|---|
| Interfaces | LAN |
| Data Storage | Measured data is saved to CF card in the EDS and/or data folder in the PC in KS2 format. |
| Channel Conditions | Measuring channel, measuring mode (strain/voltage), range, zero suppression ON/OFF, test ON/OFF, calibration coefficient, offset, unit, channel name, measuring range, rated capacity, rated output, Deci Digits (Selection of any display item is possible.) |
| Setting/Loading Parameters | Sets and loads the EDS internal parameters. |
| Collecting Data | Collects KS2 files saved in the CF card in the EDS via LAN or CF card in the PC. |
| Erasing Data | Erases KS2 files in the CF card in the EDS via LAN. |
Environmental Settings
| Hardware Configuration | Setting of connected units and device name Reading of hardware configuration from EDS-400A. |
|---|---|
| Communication Status | Checked by reading the version of the EDS |
| IP Address | Settable, from the PC via LAN. It is saved in CF card. |
Measuring Conditions for Saving Data in CF Card
| Sampling Frequencies | 1 Hz to 100 k Hz (Depends on the number of measuring channels) |
|---|---|
| Data File Size | Max. 2 GB (Depends on the number of measuring channels) |
| Measuring Modes | Manual, analog trigger, and external trigger |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| Trigger Conditions | |
| End Trigger | Settable |
| Delay | Max. 2000 data points (The delay time varies with the number of channels.) |
| Trigger Channels | Any 1 channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down or both |
Measuring Conditions for Saving Data in PC Hard Disk
| Sampling Frequencies | 1 Hz to 10 kHz |
|---|---|
| Data Files Size | Capacity of the hard disk |
| Measuring Modes | Manual, interval, and analog trigger |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. |
| Analog Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| Trigger Conditions | |
| End Trigger | Settable |
| Delay | Max. 32000 data points (The delay time varies with the number of channels.) |
| Trigger Channels | Any 1 channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down or both |
EDX-100A Control specifications
| Controllable Units | 8 (Max. 256 channels) |
|---|---|
| Interfaces | LAN, USB |
| Data Storage | Measured data is saved to CF card in the EDX and/or data folder in the PC in KS2 format. |
| Channel Conditions | Measuring channel, measuring mode, range, HPF, LPF, balance ON/OFF, CAL range, CAL ON/OFF, calibration coefficient, offset, unit, channel name, measuring range, rated capacity, rated output, Deci Digits, internal sensitivity compensation ON/OFF, offset, ZERO ON/OFF (Selection of any display item is possible.) |
| TEDS | Reads sensor's information and sets to channel condition automatically. |
| Collecting Data | Collects data saved in the CF card in the EDX via LAN or USB or directly insert the CF card in the PC. |
| Erasing Data | Erases data via LAN or USB in on-line or off-line |
| Setting/Loading Parameters | Sets and loads the EDX-100A internal parameters. |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. |
| Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| End Trigger | Settable |
| Delay | For both start and end, max. 262144 values. The delay time varies with the number of channels. |
Measuring Conditions for Saving Data in CF Card
| Data File Size | Max. 2 GB |
|---|---|
| External Trigger | Trigger slope Up, down |
| Composite Trigger | |
| Trigger Source | Selectable from 2 desired channels of stand-alone or host unit, and 1 from external trigger. |
| AND or OR | Trigger channel and external trigger can be logically determined. |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
Measuring Conditions for Saving Data in PC Hard Disk
| Data Files Size | Capacity of the hard disk |
|---|
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file in manual and interval modes. |
|---|---|
| Repetition Acquisition | In long-term data acquisition, a specified amount of data (or time) is saved in KS2 file . *Workable in manual mode (Data points preset). |
EDX-10 series Control specifications
| Controllable Units | Max. 4 (Max. 16 channels) |
|---|---|
| Interfaces | USB |
| Data Storage | Measured data is saved to data folder in the PC in KS2 format. |
| Channel Conditions | Measurement ON/OFF, mode, range, LPF, balance, calibration coefficient, offset, unit, channel name, measuring range, rated capacity, rated output, Deci Digits, chk.val.(Up), chk.val. (Down) (Selection of any display item is possible.) |
| Sampling Frequencies | 1 Hz to 20 kHz (1-2-5 series) (Depends on the number of measuring channels) |
| Measuring Modes | Manual, manual (Data points preset), interval, and analog trigger |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. |
| Analog Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| End Trigger | Settable |
| Delay | For both start and end, max. 262144 data/channel. *The delay time varies with the number of channels. |
| Trigger Channels | Any 1 channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file in manual and interval modes. |
| Repetition Acquisition | In long-term data acquisition, a specified amount of data (or time) is saved in KS2 file. *Workable in manual mode (Data points preset). |
| Environmental Settings | |
| Hardware Configuration | Setting of device name and measuring unit Configuration of device names connected to EDX-10B. Reading of hardware configuration from EDX-10B. |
EDX-200A Control specifications
| Controllable Units | Max. 8 (Max. 256 channels) |
|---|---|
| Interfaces | LAN, USB |
| Data Storage | Measured data is saved to CF card in the EDX and/or data folder in the PC in KS2 format. |
| Channel Conditions | Measurement ON/OFF, mode, range, LPF, HPF, balance ON/OFF, CAL range, CAL ON/OFF, calibration coefficient, offset, unit, channel name, measuring range, Deci Digits,,rated capacity, rated output, chk.val.(Up), chk.val. (Down), internal sensitivity compensation ON/OFF, offset ZERO ON/OFF, digital filter, sampling frequency (Select dual sampling high-speed, low-speed, high-speed + low-speed) (Selection of any display item is possible.) |
| Applicable Optional Cards | ECAN-40A CAN Data Acquisition (*1) DIO Setting (*3) ETIM-40A Interval Measurement (GPS in sync) (*1), (*2) Point Zero Measurement (Manual) (*1), (*2) GPS Data Acquisition (*1), (*2) DIO Setting (*3) EGPC-40A CAN Data Acquisition (*1) Interval Measurement (GPS in sync) (*1), (*2) Point Zero Measurement (Manual) (*1), (*2) GPS Data Acquisition (*1), (*2) DIO Setting (*3) *1: When data is saved in CF card *2: When the card is installed in host EDX *3: When control signals are from a remote control unit A. Data is saved in the CF card. B. If synchronous operation, only host EDX is settable. |
| CAN Data Acquisition | Max. 512 channels/unit of CAN data is possible. (CAN data is saved to CF card in the EDX-200A.) |
| Point Zero Manual Measurement | In multiple units of EDX-200A, allows acquisition to be started at zero second (0 ms) based on clock data of GPS satellite. |
| GPS Synchronous Interval Measurement | Allows multiple units of EDX-200A to be started acquisition based on clock data of GPS satellite. |
| GPS Data Acquisition | Monitors and records GPS data such as latitude, longitude, directions of movement, speed GPS data is saved to CF card in EDX-200A as NMEA format. |
| DIO Settings | |
| I/O Points | Max. 8 |
| I/O Settings | Sets every bit of digital input, digital output, and remote-control input. |
Measuring Conditions for Saving Data to CF Card
| Sampling Frequencies | 1 Hz to 100 kHz (1-2-5 series, 2n series, or external clock) (Depends on measuring channels. Dual sampling is supported.) |
|---|---|
| Data Files Size | Max. 4 GB |
| Measuring Modes | Manual, manual (Data point preset), interval, analog trigger, external trigger, and composite trigger |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. |
| Trigger Measurement | Start/stop recording based upon specified trigger conditions. (The trigger standard values are set absolute triggers.) |
| End Trigger | Settable |
| Delay | For both start and end, max. 262144 data/channel. (The delay time varies with the number of channels.) |
| Analog Trigger | |
| Trigger Channels | Any channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
| External Trigger Conditions | |
| Trigger Slope | Up, down |
| Composite Trigger Conditions | |
| Trigger Source | Selects from analog channels (Host EDX any 4 channels), external trigger, or manual trigger. |
| AND or OR | Trigger source can be logically determined. |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
| Repetition Acquisition | In long-term data acquisition, a specified amount of data (or time) is saved in KS2 file . *Workable in manual mode (Data points preset). |
Measuring Conditions for Saving Data in PC Hard Disk
| Sampling Frequencies | 1 Hz to 100 kHz (1-2-5 series, 2n series, or external clock) |
|---|---|
| Data Files Size | Capacity of the hard disk |
| Measuring Modes | Manual, manual (Data points preset), interval, and analog trigger |
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file in manual and interval modes. |
| Repetition Acquisition | In long-term data acquisition, a specified amount of data (or time) is saved in KS2 file. *Workable in manual mode (Data points preset). |
NTB-500A Control specifications
| Controllable Units | Max. 8 (Max. 64 channels) |
|---|---|
| Interfaces | CAN, a specified USB/CAN converter (Kvaser LEAFLIGHT HS V2) is required. |
| Data Storage | Measured data is saved to data folder in the PC in KS2 format. |
| Channel Conditions | Mode, range, zero, calibration coefficient, offset, units, measurement ON/OFF, decimal point,chk. val. (Up), chk. val. (Down), channel name, measuring range, rated capacity, rated output (Selection of any display item is possible.) |
| Sampling Frequencies | 1 Hz to 1 kHz (Depends on the number of measuring channels and the cable length) |
| Measuring Modes | Manual, manual (Preset data points), interval, and analog trigger |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. (No. of steps: 5; the interval can be changed at each step) |
| Analog Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| End Trigger | Settable |
| Delay | For both start and end, max. 262144 points/channel. *The delay time varies with the number of channels. |
| Trigger Channels | Any 1 channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
| TEDS | Reads sensor's information and sets to channel condition automatically. |
| Changing Stroke | Changes the data before the stroke and after the stroke, when using a displacement transducer. |
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file in manual and interval modes. |
| Repetition Acquisition | In long-term data acquisition, a specified amount of data (Or time) is saved in KS2 file. *Workable in manual mode (Data points preset). |
| Setting/Loading Parameters | Sets and loads the NTB-500A internal parameters. |
Environment Settings
| Hardware Configuration | Setting of connected units, communications cable length, device name, measuring unit settings Reading of hardware configuration from NTB-500A. |
|---|
UCAM-550A Control specifications
| Controllable Units | Max. 6 (Max. 300 channels) Max. 20 (Max.1000 channels), optional software DCS-106 is required. |
|---|---|
| Interfaces | LAN |
| Data Storage | Measured data is saved to data folder in the PC in KS2 format. |
| Sampling Frequencies | 1, 2, 10, 20, and 50 Hz |
| Measuring Modes | Manual, manual (Preset data points), interval, and analog trigger |
| Measuring Function | Measure: Measured value = Sensor output value - Initial value Original: Measured value = Sensor output value |
| Calibration Factor Calculation | ON/OFF setting in all channels of one batch Calibration factor compensation: Measured value x Calibration factor + Offset |
| Channel Conditions | Measurement, mode, range, calibration factor, offset, unit, initial value, channel name, measuring range, Deci Digits, chk. val. (Up), chk. val. (Down), rated capacity, rated output (Selection of any display item is possible.) |
| Initial Value Measurement | Measures the initial value of each sensor. |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. |
| Analog Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| Analog Trigger Conditions | |
| End Trigger | Settable |
| Delay | For both start and end, max. 3000 points/channel. |
| Trigger Channels | Any 1 channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
| Changing Stroke | Changes the data, before the stroke and after the stroke, when using a displacement transducer. |
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file in manual and interval modes. |
| Burnout Check | For USM-51B/52B only |
| TEDS | Reads sensor's information and sets to channel condition automatically. (USM-51B/52B only) |
| Setting/Loading Parameters | Sets and loads the UCAM-550A internal parameters. |
| Environmental Settings | |
| Hardware Configuration | Setting of connected units, device name, setting for IP address Reading of hardware configuration from UCAM-550A. |
| Communication Status | Checked by reading the version of the UCAM |
PCD-400A PCD-430A Control specifications
| Controllable Units | Max. 4 (Max. 16 channels) |
|---|---|
| Interfaces | USB |
| Data Storage | Measured data is saved to data folder in the PC (in KS2 format). |
| Channel Conditions | Measurement ON/OFF, strain mode, range, LPF, balance ON/OFF, calibration coefficient, offset, gage factor, unit, channel name, measuring range, Deci Digits, rated capacity, rated output, upper limit check, lower limit check, offset zero ON/OFF (Any display item is selectable) |
| Sampling Frequencies | 1 Hz to 10 kHz (1-2-5 series) |
| Measuring Modes | Manual, manual (Preset data points), interval, and analog trigger |
| Manual Measurement | Measurement is made from a press of the REC button to a press of the STOP button or by completion of recording using a preset number of measurements. |
| Interval Measurement | Measurement is made automatically at preset intervals from the preset starting time. |
| Analog Trigger Measurement | Start/stop recording based upon specified trigger conditions. |
| Trigger Conditions | |
| End Trigger | Settable |
| Delay | For both start and end, max. 640000 data / channel. |
| Trigger Channels | Any 1 channel |
| Trigger Level | Sets in physical quantity. |
| Trigger Slope | Up, down |
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file in manual and interval modes. |
| Repetition Acquisition | In long-term data acquisition, a specified amount of data is saved in KS2 file at specified intervals. *Workable in manual mode (Data points preset). |
| Hardware Configuration | Unit name settings possible on the PCD-400A/430A Number of connected units readable from the PCD-400A/430A |
| Automatic Data File Conversion | Automatic file conversion upon the termination of measurement (CSV, XLS, XLSX, and RPC Ⅲ formats) |
| Arbitrary Unit Settings | Up to 3 user's units of measurement are settable |
CTRS-100A Control specifications
| Number of Units | Up to 4 units (up to 128 analog channels.) |
|---|---|
| Applicable Unit | Measure unit: CTRS-CDV010A Expansion unit: CTRS-BATT010A, CTRS-SYNC010A |
| Interface | USB (USB2.0 High Speed) or Ethernet* (10/100BASE-T) *A separate synchronous unit and special communication cable are necessary. |
| Saving Format | Saves the measured data in the CTRS-100A SD card or PC folder. When saving to the SD card of CTRS-100A, save the KS3 file to the SD card of CTRS-100A Save and convert to a KS2 file (01.06) when retrieving the PC. When saving to PC folder, save as KS2 file (01.06). |
| Channel Conditions | Measuring ON/OFF, Measuring mode, Range (Arbitrary input), High-pass filter, Low-pass filter, Balance adjustment ON/OFF/NONE, Input resistance check ON/OFF, Calibr. const., Offset, Cable correction value, Offset ZERO Value, Unit, Channel name, Measuring range, Rated capacity, Rated output, Deci Digits, Chk. Val. (Up), Chk. Val. (Down), Offset ZERO ON/OFF, TEDS User Data, TEDS Sensor Model, TEDS Sensor S/N, TEDS ROMID (Display items can freely be selected.) |
| Loading TEDS Sensor Information | Loads the TEDS information automatically and sets the channel conditions. |
| Setting Parameter and Loading Parameter | Loads and sets the CTRS-100A internal parameter. |
| Saving and Loading Meas Condition File | Loads and saves the meas condition file. (Extension: C1H) The meas condition file includes environment settings, channel conditions, measuring conditions, display conditions on graphs and on numeric windows, and arithmetic operation conditions (optional). |
| Saving and Loading CTRS-100A Condition File | Loads and saves the CTRS-100A condition file (Extension: SET) by using the SD card. |
| Collecting Data File | Convert KS3 files in CTRS-100A SD card to KS2 files and recover. |
| Deleting Data File | PC deletes the file (KS3), saved in the CTRS-100A SD card. |
| Formatting SD Card | PC formats the CTRS-100A SD card. |
| Setting Environment | |
| Setting Hardware Configuration | Sets Interface, the number of units and device names. Loads the hardware configurations from the CTRS-100A. |
| Communication Check | Loads the CTRS-100A version. |
| Device Confirmation | LEDs, on the CTRS-100A front panel, light up. |
| Others | Remote control unit operation beep, balance standard value, PAUSE ON/OFF, detailed hardware information display |
When Saving the Measured Data in the CTRS-100A SD Card
| Sampling Frequency | 1 Hz to 100k Hz (1/2/5 system, 2n system, external clock) *Limited by the number of channels. |
|---|---|
| Number of Data/CH | Up to 1,000,000,000 data |
| Measure Mode | Manual, Manual (Set Record Data), Interval, Analog Trigger, External Trigger, Manual Trigger, Complex Trigger |
| Manual Measurement | Records data from REC to STOP or from REC to the number of data, specified on the Manual (Set Record Data). Recording start time: Settable |
| Interval Measurement | Records data automatically based on the pre-set starting time and recording interval. |
| Trigger Measurement | Starts/stops recording data based on the pre-set trigger conditions. |
| Common Trigger Conditions | End trigger: Settable Delay: Up to 524,288 data for both start and end. The delay time varies with the number of channels. |
| Analog Trigger Conditions | Trigger channel: Any 1 channel of the master unit Trigger level: Physical quantity Trigger slope: Positive or Negative |
| External Trigger Conditions | Trigger slope: Positive or Negative |
| Manual Trigger Conditions | |
| Complex Trigger Conditions | Trigger source: Select from the analog channels (any 4 channels of the master unit), external trigger, or manual trigger. Capable of judging the trigger source by using the logical AND and OR operators. Trigger level: Physical quantity Trigger slope: Positive or Negative |
| Repeated Recording | When recording data for a long time, the DCS-100A saves data, every pre-set number of data or every pre-set interval, in the KS3 format file. *Measure Mode: Manual (Set Record Data) only. |
| Data File | File name, File Title, Grant rule: File No or Recording start time File No: 3 to 5 digits. |
When Saving the Measured Data in the PC Folder
| Sampling Frequency | 1 Hz to 100k Hz (1/2/5 system, 2n system, external clock) *Limited by the number of channels. |
|---|---|
| File Size | Up to the data drive capacity. |
| Measure Mode | Manual, Manual (Set Record Data), Interval, Analog Trigger |
| Manual Measurement | Records data from REC to STOP or from REC to the number of data, specified on the Manual (Set Record Data). |
| Interval Measurement | Records data automatically based on the pre-set starting time and recording interval. |
| Analog Trigger Measurement | Starts/stops recording data based on the pre-set trigger conditions. End trigger: Settable Delay: Up to 524,288 data for both start and end. The delay time varies with the number of channels. Trigger channel: Any 1 channel Trigger level: Physical quantity Trigger slope: Positive or Negative |
| Static Measurement | Every time the DCS-100A starts recording data, the DCS-100A additionally saves the moving-averaged measured data in a single CSV format file. *Measure Mode: Manual and Interval only. |
| Repeated Recording | When recording data for a long time, the DCS-100A saves data, every pre-set number of data or every pre-set interval, in the KS2 format file. *Measure Mode: Manual (Set Record Data) only. |
| Data File | File name, File Title, Grant rule: File No only File No: 4 digits only. |
DCS-101A
Simultaneous Acquisition of Video and Numeric Data/Arithmetic Operations/FFT Analysis Optional Software
Specifications
Operating Environment
| OS | Windows® 7, Windows® 8.1 or Windows® 10 English/Japanese 32, 64 bits support If 64-bit OS, operate in WOW64 (Windows 32-bit On Windows 64-bit) environment. |
|---|---|
| CPU | Corei5 2 GHz or advanced * Corei5 3 GHz or advanced CPU is required for recording video, performing arithmetic operations, and FFT analysis simultaneously. |
| Memory | If 32-bit OS, 2 GB or more If 64-bit OS, 4 GB or more |
| Display | 1024x768 pixels or more |
Video Data Acquisition
| Applicable Cameras | DirectX-compatible web cameras (A web camera which the OS can recognizes as an imaging device) |
|---|---|
| Number of Applicable Cameras | 1 |
| Resolution | 640×480 pixels or more |
| Frame Rate | Max. 30 frames per second |
| Saving File Formats | AVI (Audio-Video Interleave) |
| Number of Video Capture Windows | 1 |
| Operations | Video data monitoring/recording in linkage with measuring operation Zooming *Resolution and frame rate depend on an applied camera. |
Measuring Conditions for Video Acquisition
| Applicable Instruments | EDS-400A, PCD-400A/430A, EDX-10B, EDX-100A, EDX-200A, UCAM-550A, NTB-500A, EDX-5000A and CTRS-100A |
|---|---|
| Measuring Modes | Saved in the PC: Manual, manual (Data points preset) Saved in the measuring instrument: Manual, manual (Data points preset), trigger |
Video Playback
| File Formats | AVI |
|---|---|
| Number of Playback Files | 1 |
| Number of Playback Windows | 1 |
| Operations | Play, stop, pause, frame-by-frame forward, backward, zoom, change of reproduce speed |
| Synchronized Cursors | Allows video and graphs to be reproduced with the synchronized cursors |
Arithmetic Operations
| Number of Calculation Channels | Max. 32 *Up to 64 (EDX-5000A) |
|---|---|
| Calculation Channel Conditions | Calculation ON or OFF, arithmetic expression (within 200 characters), unit, number of numeric digits on display, channel name (within 40 characters) |
| Printout | Preview and printout of calculation channel conditions possible |
| Reading & Saving | Calculated channel conditions are read and saved as a file of calculated channel condition file. Matrix conditions are read and saved as a condition file (CSV format) |
| Operations | Calculating channel data is monitored together with measuring data and saved in the same data file. |
Arithmetic Expression
| Applicable Channels | Measuring channels, calculation channels |
|---|---|
| Operators and Constants | ＋,－,＊,／,＾《 power》,PI［ π］,（ ）［parentheses］ |
| Function | SQR: Square root ABS: Absolute value SIN: Sine COS: Cosine TAN: Tangent ASIN: Arc sine (Return value: Radian) ACOS: Arc cosine (Return value: Radian) ATAN: Arc tangent (Return value: Radian) DSIN: Arc sine (Return value: Angle) DCOS: Arc cosine (Return value: Angle) DTAN: Arc tangent (Return value: Angle) LOG: Common logarithm LN: Natural logarithm EXP: Exponent HMX : Max. principal strain HMN: Min. principal strain HSM: Max. shearing strain SMX : Max. principal stress SMN: Min. principal stress SSM: Max. shearing stress DEG: Principal strain direction |
Measuring Conditions for Arithmetic Operations
| Applicable Instruments | EDX-100A, EDX-200A, EDX-10B, EDS-400A, UCAM-550A, NTB-500A, PCD-400A/430A, EDX-5000A, CTRS-100A |
|---|---|
| Data Save Folders | PC data file folders *Saves in the EDX-5000A data drive. |
| Measuring Modes | Manual, manual (Data points preset) interval, and analog trigger |
| Sampling Frequencies | Max. 10 kHz *Measuring conditions differ with measuring instruments. |
| Others | Arithmetic operations are not available when measuring the CAN data with the EDX-100A/EDX-200A. |
FFT Analysis
| Analysis Types | Linear spectrum, power spectrum, cross-spectrum, auto-correlation, and cross-correlation |
|---|---|
| Number of Analytical Data | 256, 512, 1024, 2048, 4096, and 8192 |
| Window Functions | OFF, Hamming, Hanning, Fejer, Blackman, and Gaussian |
| Number of Analytical Result Windows | Max. 8 |
| Image Display of Analytical Results | Types Graph Linear Spectrum Amplitude (Linear or log), phase Power Spectrum Amplitude (Linear or log) Cross Spectrum Amplitude (Linear or log), phase Auto-correlation Correlation Cross-correlation Correlation |
| Saving | The analysis results are saved as DAS-200A FFT analysis files (CSV format). |
| Applicable Instruments | EDX-100A, EDX-200A, EDX-10B, EDS-400A, NTB-500A, PCD-400A/430A, EDX-5000A, CTRS-100A *Measuring conditions differ with measuring instruments. |
DCS-104A
GPS Data Acquisition Optional Software
Specifications
Operating Environment
| OS | Windows Vista®, Windows® 7, Windows® 8, 8.1 or Windows® 10, English/Japanese 32, 64 bits support |
|---|---|
| CPU | Core2Duo, 2 GHz or advanced |
| Memory | If 32-bit OS, 2 GB or more If 64-bit OS, 4 GB or more |
| Display | 1024 x 768 pixels or more |
GPS Data Acquisition
| GPS Data Display | During monitoring and acquisition,arbitrary selection of latitude, longitude,direction of movement, speed, reception status,and number of received satellites for display is possible. |
|---|---|
| GPS Data Files Formats | NMEA-0183 (Extension: NMEA) In the same folder as the acquisition data KS2 files, these are saved as a separate file with the same name as the KS2 file. |
Applicable GPS Receivers
| Interface | RS-232C or USB connection (If USB connection, then a USB-to-serial port converter driver enables equivalent RC-232C connection) If the PC does not have a COM port, then to connect using RS-232C, use a RS-USB conversation adapter. |
|---|---|
| Output Format | NMEA-0183 |
| Geographical Coordinates | WGS-84 |
| Connected Units | 1 |
| Models Confirmed to Operate | HOLUX Comet USB/3XHL SanJose Antares 48USB/UBX5 |
Measuring Conditions
| Applicable Instruments | PCD-400A/430A, EDS-400A, EDX-10B,EDX-100A, EDX-200A |
|---|---|
| Measuring Modes | Saved in the PC:Manual, manual (Data points preset) Saved in the measuring instrument:Manual, manual (Data points preset), trigger *Measuring conditions differ with measuring instruments. |
DCS-105A
CANdb file read optional software
Specifications
Operating Environment
| OS | Windows Vista®, Windows® 7, Windows® 8, 8.1 or Windows® 10, English/Japanese 32, 64 bits support |
|---|---|
| CPU | Core2Duo, 2 GHz or advanced |
| Memory | If 32-bit OS, 2 GB or more If 64-bit OS, 4 GB or more |
| Display | 1024 x 768 pixels or more |
| Applicable Instruments | EDX-100A, EDX-200A |
| CANdb File Read | Sets CAN condition of DCS-100A by reading CANdb file. |
| Applicable Conditioner Cards | CAN-41A |
|---|---|
| Applicable Card for Optional Slot | ECAN-40A (EDX-200A optional card) EGPC-40A (EDX-200A optional card) |
DCS-106A
1000-channel for UCAM-550A Optional Software
Specifications
Operating Environment
| Applicable Instruments | UCAM-550A |
|---|---|
| OS | Windows Vista®, Windows® 7, Windows® 8, 8.1 or Windows® 10, English/Japanese 32, 64 bits support |
| CPU | Intel Core i5 2.6 GHz or advanced |
| Memory | If OS is 32-bit OS, 2 GB or more If OS is 64-bit OS, 4 GB or more |
| Display | 1024 x 768 pixels or more |
| Number of Acquisition Channels | Enables UCAM-550A (20 units) to perform measurement in 1000 channels. |
Page Top
Download
-
